300kgh Semi-Automatic Wave Shape Potato Chips Production Line include potato washing & peeling machine, potato cutting machine, potato blanching machine, potato dehydrator machine, potato frying machine, potato oil removing machine, potato stick or chips flavouring machine and potato vacuum packing machine.
1. Potato Washing & Peeling Machine
Potato Washing and Peeling Machine is used for peeling many kinds of fruit and vegetable, such as potato, sweet potato, dasheen, turnip, carrot, kiwi fruit, etc. Potato Washing and Peeling Machine has high peeling rate up to more 98%.
Specification
- Power：3KW
- Weight：460kg
- Output: 2500kg/h
- Outline Dimension：2900*840*900mm
- Material: SUS304 Stainless Steel Made
2. Potato Stick & Chips Cutting Machine
Wave Shape Potato Sticks Cutting Machine include two process, first, Machine cut the potato into potato chips and then it is cutted to wave shape stick by wave shape knife. After cutting, the surface of potato or carrot is smooth. The processing material is suitable for steam processing, boiling process, fry processing.
Specification
- Power：1.1kw/ three phase
- Output：800kg/h-1000kg/h
- Dimension：1745*580*1030
- Weight：180kg
- Material: SUS304 Stainless Steel
3. Automatic Discharging Blanching Machine
Automatic Discharging Potato Chips Blanching Machine is used for pretreatment of meat product, Fruit and Vegetable Processing, Seafood products. Blanching machine is made of stainless steel SUS304. The blanching temperature and speed can be set according to different requirement. Vibrable frequency motor, automatic temperature control, with low noise and stable running condition. Automatic discharging design make the blanching machine realize fast operation and large capacity.
Specification
- Dimension: 1680*2050*1500mm
- Weight: 580kg
- Power: 79KW
- Material: SUS304 Stainless Steel
4. Dehydrator Machine
Dehydrator Machine is equipped with shape reduction system, which avoid vibrate during dehydrating processing and avoid damage to the machine. Our dehydrator machine also adopt frequency control of motor speed and movable rotary drum, which makes the machine easy to use.
Specification
- Power: 2.2KW
- Weight: 700kg
- Dimension: 1280*820*1000mm
5. Automatic Discharging Potato Chips Frying Machine
Automatic Discharging Potato Chips Frying Machine adopt stainless steel made, which allow customer to set temperature. Automatic discharging design makes the frying machine can operate faster and safe.
Specification
- Power: 63KW
- Weight: 380kg
- Dimension: 2350*1050*1200mm.
- Material: SUS304 Stainless Steel Made
6. De-oiling Machine
De-oiling Machine is equipped with shape reduction system, which avoid vibrate during oil removing processing and avoid damage to the machine. Our oil removing machine also adopt frequency control of motor speed and movable rotary drum, which makes the machine easy to use.
Specification
- Power: 2.2KW
- Weight: 700kg
- Dimension: 1280*820*1000mm
7. Flavoring Machine
Specification
- Power: 1.1kw
- Capacity: 400kg/h
- Weight: 120kg
- Dimension: 1060*1000*1550mm
8. Double Chamber Vacuum Nitrogen Packing Machine
Double Chamber Vacuum Nitrogen Packing Machine has two vacuum chamber. When one chamber working, worker can layout the bag on another chamber. This design makes the vacuum packing process faster.
Specification
| Power（kw） | 3.5 |
| Packing Speed（time/h） | 120-180 |
| Sealing Size（mm） | 800×10mm/2pcs |
| Vacuum Chamber Size（mm） | 910×780×190 |
| Outline Dimension（mm） | 1840×960×1100 |
| Material | thickness 6mm/ sus304 stainless steel |
Working Video of Semi-Automatic Wave Shape French Fries Production Line
Note: some machine need to change to get the final product you want
